Biolase Waterlase iPlus

Biolase Waterlase iPlus All-Tissue Dental Laser | MedicalZenith

$11,075.00

Biolase Waterlase iPlus All-Tissue Dental Laser System

Overview

The Biolase Waterlase iPlus is a market-leading all-tissue dental laser system that combines Er,Cr:YSGG laser energy with air and water spray to perform hard tissue, soft tissue, and bone procedures with minimal invasiveness. Unlike conventional dental drills, the Waterlase iPlus reduces heat, vibration, and pressure during treatment, often eliminating the need for local anesthesia in restorative procedures. With over 80 FDA-cleared indications, this system is designed for general dentistry, periodontics, endodontics, and oral surgery applications.

Key Features

SureFire YSGG Delivery System — precision fiber delivery for consistent, ergonomic handpiece control

REPAIR Perio & REPAIR Implant Protocols — dedicated software modes for periodontal and peri-implantitis treatment

Touchscreen Interface — pre-programmed procedure settings with full manual customization

Dual Handpiece Configuration — includes Gold Handpiece and Turbo

Technical Specifications

Laser Class
4
Laser Medium
Er,Cr YSGG (Erbium, Chromium – Yttrium, Scandium, Gallium, Garnet)
Wavelength
2780 nm
Frequency
5–100 Hz
Average Power
0.1–10.0 W
Power Accuracy
±20%
Pulse Energy
0–600 mJ
Pulse Duration (H Mode)
60 µs
Pulse Duration (S Mode)
700 µs
Water Type
Distilled, De-ionized, or Sterile
External Air Source
80–120 psi (5.5–8.2 bar)
Interaction Zone
0.5–5.0 mm
Handpiece Head Angle
70° Contra Angle
Gold HP Tip Diameter Range
200–1200 µm
Turbo Tip Focal Diameter Range
500–1100 µm
Aiming Beam
635 nm (red), 1 mW max
NOHD (Nominal Ocular Hazard Distance)
5 cm
Dimensions (Unit)
11" x 19" x 33" (28 x 48 x 84 cm)
Weight
75 lbs (34 kg)
