Cutera Trusculpt 3D PRODUCT SPECIFICATIONS

Cutera Trusculpt :Energy Type: Radio Frequency

Massage: Yes

Temperature Sensing: Yes

Temperature Sensing Active Control: Yes

Treatment Activation: Fingerswitch

Area Treated: 16, 25, and 40 cm2

Electrode Shape: Square or Rectangle

RF Frequency: 1 MHz and 2 MHz

Max RF Power: 300 W

Contact Material: Polyethylene (3M Tegaderm) and 316 SS

RF Output: 1 MHz

Voltage Range: 250 Vrms

Max Max Output: 300 W

Voltage: 100-240 Volts

Frequency: 50/60 Hz

Power: 900 VA Console

Dimensions: 12.5 x 20.5 x 36 inches

Console Weight: 73 lb 40 cm2

Handpieces:

3D 40 cm2 Body Handpiece: for larger areas, including the abdomen and flanks

16 cm squared Handpiece: for small areas, petite patients or anatomically difficult areas, like the neck

Cutera Trusculpt 3D MANUFACTURER NOTES

truSculpt® 3D – A New Dimension in Body Sculpting

The rise in popularity of body sculpting can be attributed to two main factors: improved non-surgical treatment results and a population that values investing in themselves.

The truSculpt 3D body sculpting device is ideal for patients and practitioners alike. TruSculpt 3D is a unique, non-invasive, Monopolar RF system optimized to deliver Targeted, Repeatable and Uniform sculpting of problem areas for a TRU 3D result with no visual downtime. truSculpt 3D takes a multi-dimensional approach to decrease circumference and eliminate fat cells, by delivering and holding clinically therapeutic temperatures to the subcutaneous adipose tissue to achieve the clinical efficacy in the shortest possible treatment time with enhanced safety and comfort.

truSculpt 3D Technology

Experience TRU 3D Body Sculpting

Glide Technique

Achieve double the results in half the time with the truSculpt 3D glide technique that offers consistently impressive results in a shorter treatment time over a larger treatment zone.

Combine four 15-minute treatment zones in one session for maximum results in the most common treatment areas — the abdomen and flanks.

truSculpt 3D glide technique offers consistently impressive results – an average of 24% fat reduction, in a short treatment time over a large treatment zone. One 60-minute session provides clinically proven results in the most common treatment areas – the abdomen and flanks.

Targeted RF Energy

The truSculpt 3D system uses a low frequency and high conductivity radiofrequency (RF) technology for deep penetration to treat the entire fat layer from skin to muscle while maintaining a comfortable surface temperature for patients. The fat cells are slowly removed and excreted through the body naturally.

Repeatable, Proven Outcomes

truSculpt 3D features a proprietary closed-loop temperature feedback mechanism that ensures therapeutic temperatures are met throughout each treatment. This means your patients are comfortable while consistently achieving results.

Uniform Delivery

truSculpt 3Ds patented handpiece design delivers uniform heat to the targeted area. The signature design eliminates potential hot spots and not only enhances patient safety and comfort but ensures that your patients get results. Now you can offer your patients the look they want with a fast, comfortable, non-invasive procedure.

Cutera truSculpt 3D Handpieces

• 3D 40 cm2 Body Handpiece: for larger areas, including the abdomen and flanks
• 16 cm squared Handpiece: for small areas, petite patients or anatomically difficult areas, like the neck

truSculpt 3D gives you the flexibility to non-invasively address the most common body sculpting concerns. With truSculpt 3D’s two handpiece options (40 cm2 and 16 cm2), you can decrease circumference and eliminate unwanted fat from large and small areas.
