ASCLEPION TATTOOSTAR EFFECT LASER WITH HANDPIECES
Asclepion TattooStar Effect Q-Switched Nd Yag Laser
Laser Type:Q-Switched Nd Yag Laser
Wavelength:532 and 1064nm
Optional Wavelength Handpiece:585 nm Dye
Pulse Rate:Max 10 Hz
Pulse Duration:Q-Switched-mode approx. 8 ns; Free-running-mode max. 250 us
Fluence:1064 nm max. 37 J/cm2; Q-Switched max. 20 J/cm2; 532 nm max. 10 J/cm2
Spot:2.5 mm, 4 mm, 5.5 mm; optional 2 mm; Free running 7 mm (square shape)
Laser Class:4
The best Q-switched Nd:YAG laser on the market
The TattooStar Effect is extremely effective in the removal of tattoos and pigmented lesions. Treatment using the TattooStar is quick and nearly painless, bloodless, without causing injury or leaving scars.
INDICATED USES:
Tattoo Removal
Pigment Removal
Asclepion TattooStar Effect Q-Switched Nd Yag Laser
FAST, EFFECTIVE AND NON-INVASIVE.
Q-switched Nd:YAG dual wavelength (1064/532nm)
Two wavelengths give physicians the flexibility to adapt treatments precisely to the patients needs and to a wide range of pigment colors (from darker colors to red). The ultra-short pulses of the Q-switched make it possible to burst the particles without any thermal side effects or scars. This increases patient comfort.
Reliable, fast and powerful ASCLEPION TATTOOSTAR EFFECT LASER WITH HANDPIECES
The TattooStar can be operated for a long duration, even in regions with higher temperatures and higher humidity, at a maximum speed of 10 Hz. This makes it one of the fastest and most reliable systems on the market. Its unmatched power output enhances your application spectrum, in addition to providing greater flexibility and efficiency.
Squared-shaped spot with automatic spot size detection
The special shape of the TattooStar spots is designed to guarantee the optimum coverage of the treatment area with greater efficiency. Unlike conventional circular spots, the square spot prevents gaps and overtreatment. Automatic spot detection allows different conditions on every part of the body to be treated in a fast, safe and efficient way.
Microlens array with homogeneous spot
An exclusive system with microlenses from Asclepion Laser Technologies replaces the traditional lens system. It creates a homogeneous spot (as opposed to a hot spot) by distributing the laser energy in a perfectly uniform way. This eliminates the need for overlap and prevents over-treatment. This results in less pain and lower bleeding levels. In short, the microlens array provides improved treatment and healing.
Touch screen and user-friendly interface
Asclepion TattooStar Effect Q-Switched Nd Yag Laser
The TattooStar Effect Y features a 12 display with an easy-to-use, color touch screen. This tool has been thoroughly inspected and approved for use by doctors during treatments. Doctors can show videos of treatments to their patients, choose the indication, and have the corresponding parameters set automatically. During treatment, they can constantly refer to the display for procedure suggestions.
Patients gain reassurance about the procedure and the results by watching the video and viewing the before and after pictures. As a unique feature, the display may be detached from the device and used as a tabletop digital support when meeting with patients. Doctors can also work with the new widely-used Windows® interface to create a patient database.
Dye handpiece (585 nm)
A special dye handpiece that changes the wavelength from 532 nm to 585 nm allows for treating an even broader color spectrum, such as blue tattoos. It is even effective on tattoos that were previously treated with other lasers and are grey or pale as a result.
