Ellman Medley Sparkling Multi-Platform Device with 4 Handpieces: 810 Diode, 2940 Erbium YAG, IPL, and Q-Switched Nd YAG
Upgrade your skincare and aesthetics game with the Ellman Medley Sparkling Multi-Platform Device. This versatile device comes equipped with four powerful handpieces, each designed for specific applications. Let’s explore the capabilities of each handpiece:
Q-Switched Nd Yag Handpiece
Application: The Nd Yag handpiece boasts two wavelengths (1064 nm and 532 nm), making it ideal for treating vascular lesions like facial veins, telangiectasias, angiomas, hemangiomas, and pigmented lesions.
Energy: Delivering up to 1000 mJ, it ensures effective treatment.
Maximum Fluence: Up to 12 J/cm2.
Wavelengths: 1064 nm and 532 nm.
Spot Size: Adjustable from 1.5 to 4 mm with a zoom lens.
Pulse Width: Ranging from 10 to 15 ns.
Repetition Rate: Customizable from 1 to 6 Hz.
NOHD: Protecting your safety with a rating of over 1000 m.
Aiming Beam: Equipped with a diode (635 nm, 10 mW Max.) for precision.
Beam Delivery: Direct for accuracy.
Controls: User-friendly touch screen LCD and a footswitch for convenience.
Cooling: Efficient self-contained closed-loop cooling system.
810 nm Diode Laser Handpiece
Application: Perfect for laser hair removal, this handpiece operates at 810 nm.
Spot Size: Offers a comfortable 10 x 14 mm spot size.
Repetition Rate: Adjustable from 1 to 10 Hz for quick treatments.
Fluence: Customizable from 1 to 100 J/cm2.
NOHD: Ensures safety with a rating exceeding 30.1 m.
Pulse Width: Various settings, including auto, 30 ms, 100 ms, 200 ms, and 400 ms.
Accuracy: Maintains precision within +- 10%.
Cooling Temperature: Keeps you comfortable with a range of 0 to 5°C.
IPL Handpiece
Application: Offering four wavelengths (650 nm, 540 nm, 510 nm, and 450 nm), this handpiece tackles a range of concerns, from hair removal to pigment reduction and more.
Maximum Fluence: Up to 35 J/cm2 for effective treatments.
Wavelength: Covers 450 to 1200 nm.
Spot Size: Comfortable 35 x 15 mm spot size.
Repetition Rate: 1 pulse every 3 seconds.
Cooling: Relies on a self-contained closed-loop system for consistent performance.
Indicated Uses for Ellman Medley Sparkling Multi-Platform Device with 4 Handpieces:
- Tattoo Removal
- Pigmented Lesions on Skin Types IV
- Active Acne
- Uneven Pigmentation
- Vascular Lesions
- Hair Removal
- Superficial Skin Resurfacing
- Fine Lines and Wrinkles
- Micro-Laser Peels
- Sun Damaged Skin
Specifications:
Application: Ideal for laser skin resurfacing, skin ablation and coagulation, and reducing wrinkles and scars.
Energy: Delivers up to 1000 mJ.
Max Power: 2.4 W.
Pulse Width: Precise control with 300 us.
Wavelength: Operates at 2940 nm.
Beam Divergence: Collimated for accuracy.
Spot Size: Adjustable from 1.5 to 6 mm with a zoom lens.
NOHD: Ensures safety with a rating exceeding 180 m.
Repetition Rate: Capable of up to 8 pulses per second.
Controls: Easily adjustable with a touch screen LCD and footswitch.
Cooling: Efficient self-contained closed-loop cooling system.
Experience the ultimate in skincare technology with the Ellman Medley Sparkling Multi-Platform Device. Unlock a world of possibilities for your skin and aesthetic needs.
